• Master Power Natural Gas Generator with extended warranty for peace of mind
1 1

4500 kW (4.5 mW) Prime Power Natural Gas Generator (480/277V Three Phase 60Hz)

4500 kW (4.5 mW) Prime Power Natural Gas Generator (480/277V Three Phase 60Hz)

Shipping calculated at checkout.

Contact for Quote View full details
*All Pictures shown are for illustration purposes only. Actual product may vary due to enhancement*

1-year/3000 hours Warranty with Free parts and service guidance!

Model

Rated Power

4500 kW (4.5 mW)

5625 kVA
Fuel Type

Natural Gas (PNG)

Output

Voltage

480/277V
Phase

3 Phase 4 Wires
Frequency

60 Hz
Rated Speed

1800 RPM
Power Factor

0.8
Engine Manufacturer

Baudouin
Alternator Manufacturer

Stamford
Control Module Manufacturer

Deep Sea
Parallel Circut Breaker

ABB/4P/E1B 1600 D LI FF 4P NST Intelligent Circuit Breaker
Solenoid Valve

DUNGS, Germany or Honeywell, USA
Pressure Regulating Valve

MADAS, Italy
40HQ Silent Containerized Enclosure Treatment

Acid Pickling and Phosphating Treatment, Anti-rust, Anti-corrosion
Dimensions
(L x W x H) mm

12,030 x 2,440 x 2,380
Approximate Weight (kg)

13,500 kg

Standard configuration

Pressure regulating valve, filter, flame arrester, flange, DN80 flange, Maintenance free battery, battery connector, Shock absorbing pad, Muffler (Installed), etc.

Each machine is equipped with a Gas leak alarm, an explosion-proof lamp, Automatic shut-off valve.

  • Copper 50° Radiator
  • 24V DC Start Motor
  • High-Performance Circuit Breaker
  • Linear Vibration Isolators between the Base and Engine-Generator
  • Liquid Cooled

2 Separate Cooling Systems

  1. High-temperature circuit equipped with a thermostatically-controlled system with two gear-driven coolant pumps
  2. Low-temperature circuit equipped with belt-driven coolant pump.
